This means that the BSL entry sequence was successful. After a second both the red and green LEDs should light steadily.

Plug in the USB from the Launchpad USB to the PC.

I disconnected the Launchpad USB from the PC and made the connections listed above with jumper wires.

I loaded the code from slaa535 onto my G2452 (with project setting changed for G2452 since that was what I had).

MSP-EXP430FR5739 board - all jumpers on J3 removed, and I am not using the mini USB port (I'm powering the board from the launchpad). Launchpad Rev 1.4 with a G2452 (this was the value line part I happened to have lying around). I just tried using the launchpad BSL scripter setup from slaa535 with an MSP-EXP430FR5739 Experimenter's board and it worked for me.

#FRAMING ERROR COOLTERM SERIAL#

I attached the serial frame grabbed with my logic analyser. The packet size given is too big for the RX buffer" I think that my MSP430 is successfully entering in the BSL, but when I try to send any command with the BSL_Scripter I always get the error "0x54 - Packet size exceeds buffer. I did what is explained in the application note SLAA535A. I'm trying to send commands to my BSL using the MSP430 Lauchpad and BSL_Scripter.
